Bending system with double Double Cylinder on the upper table.
Static and dynamic rigidity provided, strong construction with steel frame and upper table material.
Upper table movement supported by easily adjustable fiber slide bearings.
Durable balancing spindle and eccentric spindle balls that aid parallelism.
High stroke and front opening values that facilitate the use of different bending molds.
Hydraulic safety system against excessive pressure rise.
Double speed working system: Free Fall, Bending, Return Back
Compact, low maintenance REXROTH or HOERBIGER hydraulic system unit located at the back-top of the machine.
European origin SIEMENS electrical equipment.
Thanks to LEUZE brand forsecurity system, the front barrier bending in different forms with learning mode.
Cybtouch 12 CNC Control Unit
OPKON Linear Magnetic Encoder
Standard upper tools and Bottom Die
Motorized X and motorized R-axis (OPTION) back gauge with motorized X and motorized R axes that can move at high speed and programmed via CNC control supported with linear guideways: 500 mm back gauge distance and 0.1 mm operating precision, the gauge height is precisely adjusted.
Manual crowning system and Manual adjustable wedges foraligning the top tools.
Quick-releasetop tool clamping system for partial and quick removing.
Multi-function foot pedal
Front support arms that can be easily moved with linear slide and bearing systems.
Optional Features
Special bending dies.
Special safety systems. (DSP, FIESSLER)
Extended backgauge length
Extra back gauge fingers
Extra front support arms
Motorized R-Axis with precision movement
Servo motorized system backgauge system ( X Axis )
